Yeastar TA Series FXO VoIP Gateway

Businesses of all sizes can rely on this innovative solution

Toll-quality voice call and top performance and reliability

Yeastar TA FXO VoIP Gateways provides 4, 8, or 16 ports to connect analogue telephone lines or PABX extension interface to VoIP networks. It is a cost-effective and reliable solution for office-to-office voice connectivity.

Benefits

High Performance

Superb voice compression with industry standard codecs.Tested and certified with Elastix and compatible with other IP systems

Auto Provisioning
Support PnP or DHCP provisioning by Yeastar PBX and standard open protocol TR-069

Feature-rich

A robust feature set that fulfils your various needs and cuts communication cost

Simple and Easy

User-friendly Web GUI and intuitive operations. Comprehensive call log, system logs, hardware logs, and debug logs

Key Features

Answer Detection
API
Attack Alert
Auto Provisioning with Yeatsar PBX
Backup and Restore
Call Back
Call Detail Records
Caller ID Display
Firewall
Firmware Upgrade by HTTP/TFTP

Hangup Detection
Hotline
IP Blacklist
Nat Traversal
Packet Capture Tool
Programmable AC Impedance
System Logs
Two-stage Dialing
Web-based Management
Remote Management

Specifications

Models	TA410	TA810	TA1610
RJ11 FXO Ports	4	8	16
RJ 21 Ports	一	一	1
LAN	1 10/100Mbps
WAN	一		1 10/100Mbps
Protocol	SIP (RFC3261), IAX2
Transport	UDP, TCP, TLS, SRTP
Codec	G.711 (alaw/ulaw), G.722, G.723, G.726, G.729A, GSM, ADPCM
Voice Capability	ITU-T G.168 LEC Echo Cancellation, Dynamic Jitter Buffer, VAD, CNG, PLC
DTMF Mode	RFC2833, SIP Info, In-band
Fax	T.30
QoS	DiffServ, ToS, 802.1 P/Q VLAN tagging
Network	DHCP, DDNS, OpenVPN, PPPoE, Static Route, VLAN
Network Protocol	FTP, TFTP, HTTP, HTTPS, SSH
Management Protocol	RADIUS		–
Remote Management	N/A		Yes
Signalling	FXS Loop Start, FXS Kewl Start
Caller ID	BELL202, ETSI (V23), NTT (V23-Japan), and DTMF-based CID
Disconnect Methods	Busy Tone, Polarity Reversal
FXO Connectivity	Programmable AC Impedance, Hangup Detection, Answer Detection, Caller ID Detection
Power	12V, 1A		AC 100-240V (12V 5A)
Dimensions (L × W × H) (mm)	200 × 137 × 25		440 × 250 × 44
Operation Range	0°C to 40°C, 32°F to 104°F;
Storage Range	-20°C to 65°C, -4°F to 149°F
Humidity	10-90% non-condensing
Mounting	Desktop, Wall-mount		Desktop, Rack-mount
Compatibility	Interoperable with Asterisk, Lync Server, FreePBX and certified with Elastix.
